Product characteristics
▶ Multiple intelligence combination：Intelligent dynamic group; Network and unnetwork function, and network self-healing ability
▶ A variety of networking methods：Support LAN/WiFi; Two ways to connect to the network
▶ Remote one-click off：Intelligent monitoring management platform, can remotely one-click off component output
▶ Strong anti-interference ability：Support data breakpoint continuation, to solve the problem of data packet loss
Argument
|
Model number |
Swarm |
|
Basic parameter |
|
|
Supply operating voltage |
12 Vdc |
|
Working current |
25 mA |
|
Power dissipation |
≤0.3 W |
|
Installation specification |
|
|
Communication interface |
RS485*2 |
|
Communication distance |
(Swarm to Honeybee)≤30m |
|
Radio frequency band |
868M/915M/2.4G Hz |
|
The number of optimizers can be collected |
≤200 |
|
dimension |
124x99x32 mm |
|
weight |
150 g |
|
Operating temperature |
-40～+85℃ |
|
Class of protection |
IP65 |
|
Standard / Certification |
|
|
CE |
EN 62368-1:2020+A11:2020 |
|
WEEE |
EN 50419:022 |
|
RoHS |
2011/62EU 2015/863EU |
