Features
Intelligent Dynamic Mesh Network with Meshing and Unmeshing Functions, as well as Network Self-Healing Capability
Multiple Networking Modes: Supports both LAN/WiFi connection modes
Remote One-click Shutdown: Intelligent monitoring and management platform enables remote one-click shutdown of component outputs
Strong Anti-interference Capability: Supports data breakpoint resumption to solve data packet loss issues
Parameters
|
Model |
Swarm |
|
Basic Parameters |
|
|
Supply Voltage |
12VDC |
|
Operating Current |
250mA |
|
Power Consumption |
≤0.3W |
|
Installation Specifications |
|
|
Interface |
RS485*2 |
|
Communication Distance |
(Swarm to Honeybee) ≤30m |
|
Wireless Communication Frequency |
868M/915M/2.4GHz |
|
Number of Optimizers Collected |
≤200 units |
|
Dimensions |
124x99x32 mm |
|
Weight |
155 g |
|
Operating Temperature |
-40°C to +85°C |
|
Protection Level |
IP65 |
|
Safety Standard |
EN 62368-1:2020+A11:2020 |
|
Communication |
EN 50663:2017, EN 62479:2010 |
