Data collector Swarm PLC (wired)

language

get a quote

Home > Product > Monitoring Equipment > Data collector Swarm PLC (wired)

Product Description

Product characteristics

Multiple intelligence combination：intelligent dynamic group; Network and unnetwork function, and network self-healing ability

A variety of networking methods：support LAN/WiFi; Two ways to connect to the network

Remote one-click off：monitoring management platform, can remotely one-click off component output

Strong anti-interference ability：support data breakpoint continuation, to solve the problem of data packet loss

argument

Model number	Swarm-PLC
Basic parameter
Number of strings supported	4
Single string maximum input current	20 A
Support system voltage	1000V/1500V
expandability	Supports a maximum of 10 Swarm PLC cascades
Supply operating voltage	12 Vdc
Installation specification
connector	Compatible with MC4 and Staubli
dimension	140x99x50.4 mm
weight	504 g
Operating temperature	-40～+85℃
Class of protection	IP65
Feature
Communication mode	RS485
Local quick shutdown function	support
Remote shutdown function	support
Safe open circuit voltage	support
The power grid automatically shuts down after power failure	support
Supported product model	Honeybee400/650/850/1600(PLC)
Standards/Certification
Laws and regulations	NEC2017/2020690.12
secure	IEC/EN62109-1:2010 the Low Voltage Directive(2014/35/EU) UL1741,UL3741, CSA C22.2,UL1703
EMC	ENIEC61000-6-2:2019 EN61000-6-3:2007/+A1:2011 the EMC Directive(2014/30/EU)

Product Documents
